Description
- Features
- Display mode: B, B + B, 4B, B + M, M.
- Measurement, distance, circumference, area, volume, heart rate, pregnancy week (BP, GS, CRL, HC, AC, EDD, AFI) and the expected date of birth, fetal weight display, etc.,
- Electronic focus: four electronic focus
- Body mark: ≥ 90 kinds
- Image mirroring: up and down, left and right, black and white , in any mode can be changed and operated.
- Images can be 0 °, 90 °, 180 °, 270 °, 360 ° rotation
- Through the trackball cursor to select the function package and measurement methods
- Character display: date, time, name, sex, age, doctor, hospital, comment (full screen character editing) (can be mixed with letters, numbers, punctuation, arrows)
- Cine loop: ≥ 512 frames, can be continuous to play or view by line.
- Permanent storage: built-in 8G memory, ≥ 4000 images, support U disk storage (can be read)
- Puncture guidance function;
- Four kinds of frame correlation, with independent keys, can be adjustable, can be adjusted, you can also change by trackball cursor;
- 6 kinds of line correlation, with independent buttons, can be adjustable, recycled visual adjustment, you can also change the trackball cursor.
- 8 kinds of gamma correction, with independent buttons, can be adjustable, recycled visual adjustment, you can also change the trackball cursor.
- Edge enhancement, 0-3, 4 kinds of adjustment, with independent keys, can be adjustable visually, can be adjusted cyclically, you can also change by trackball cursor;
- Scanning range, 0-3, 4 kinds, with independent keys, adjustable, can be adjusted cyclically, you can also change by the trackball cursor;
- Interface: RS-232 , VGA , VIDEO , 2 USB ports, DICOM
III. Specifications
- Main unit system:
- a) Digital beamforming
- b) Real-time dynamic aperture imaging
- c) real-time dynamic sound velocity trace
- d) 8-segment digital TGC
- e) Tissue harmonic imaging unit
- f) Dynamic digital filtering
- g) image enhancement, row correlation, frame correlation, point correlation, linear interpolation and other image processing technology
- probe interface
- Function introduction
PARAMETER | SPECIFICATION |
Display mode | B, B + B, 4B, B + M, M. |
measurement, distance, circumference, area, volume, heart rate, pregnancy week (BP, GS, CRL, HC, AC, EDD, AFI) and the expected date of birth, fetal weight display, etc | |
electronic focus | four electronic focus |
body mark | ≥ 90 kinds |
Image mirroring | up and down, left and right, black and white , in any mode can be changed and operated. |
images can be 0 °, 90 °, 180 °, 270 °, 360 ° rotation | |
through the trackball cursor to select the function package and measurement methods | |
Character display | Character display 9. cine loop: ≥ 512 frames, can be continuous to play or view by line. |
permanent storage | built-in 8G memory, ≥ 4000 images, support U disk storage (can be read) |
puncture guidance function; | |
0-3, four kinds of frame correlation, with independent keys, can be adjustable, can be adjusted, you can also change by trackball cursor; | |
6 kinds of line correlation, with independent buttons, can be adjustable, recycled visual adjustment, you can also change the trackball cursor. | |
0-7, 8 kinds of gamma correction, with independent buttons, can be adjustable, recycled visual adjustment, you can also change the trackball cursor. | |
edge enhancement, 0-3, 4 kinds of adjustment, with independent keys, can be adjustable visually, can be adjusted cyclically, you can also change by trackball cursor; | |
scanning range, 0-3, 4 kinds, with independent keys, adjustable, can be adjusted cyclically, you can also change by the trackball cursor; | |
scanning range, 0-3, 4 kinds, with independent keys, adjustable, can be adjusted cyclically, you can also change by the trackball cursor; | |
Interface: | RS-232, VGA, VIDEO, 2 USB ports, DICOM |
- Product configuration
Main unit:
Main unit, power adapter PH80, 3 × 0.75MM power cord
12.1 inch medical LED display, 10400mA lithium battery
Gross Weight: 9.5KG
Manual
Warranty Card Certificate
Packaging plastic bags
Desiccant
Paper box
3.5MHz 80-element convex probe (optional)
6.5MHz 80-element micro-convex probe (optional)
7.5MHz 80-element rectal probe (optional)
7.5MHz 80-element high-frequency linear array probe (optional)
6.5MHz 80-element rectal probe (optional)
7.5MHz 80-element back fat probe (optional)
Frequency range:
3.5MHz: 2.0MHz, 2.5MHz, 3.5MHz, 4.0MHz, 5.0MHz
5.0 MHz, 4.0 MHz, 4.5 MHz, 5.0 MHz, 6.5 MHz, 7.0 MHz
6.5 MHz: 5.0 MHz, 5.5 MHz, 6.5 MHz, 7.5 MHz, 8.5 MHz
7.5 MHz: 5.5 MHz, 6.5 MHz, 7.0 MHz, 7.5 MHz, 9.0 MHz
- Technical Specifications
PARAMETER | SPECIFICATION |
gray scale | 256 level |
Grayscale | 7 kinds, can be adjustable |
Dynamic range | 0-135dB |
Resolution | horizontal ≤ 2mm; longitudinal ≤ 1mm |
Focus points | 1-4 focus optional, adjustable focus position continuously |
STC Gain Adjustment | 8 segments |
Tissue Harmonics | 0-1MHZ |
Maximum scan depth | 3.5mhz ≥ 307mm Visual adjustable
5.0MHz: 62-180mm 6.5MHz: 62-139mm 7.5MHz: 35-104mm |
Zoom function | Overall zoom |
Image level adjustment | 0-1 |
black and white flip | 0-1 |
depth adjustment | 16 level |
Gain | 0 ~ 100 adjustable. |
scanning speed | 0-7 |
M pseudo color | 0-7 |
Blind zone | ≤ 4 |
Geometric accuracy | horizontal ≤ 5%, vertical ≤ 5% |
Resolution | lateral ≤ 2mm, axial ≤ 1mm |
