Pachymeter AM-2100S
- Home
- Pachymeter AM-2100S
Personal Protective Equipment
Laboratory Equipment
Operating Theatre Equipment
Introduction
2100S Ophthalmic A-Scan/Pachymeter with macular recognition function, can accurately measure axial length, anterior chamber depth, lens thickness, as well as intra-ocular lens calculation. And also with the central area and the peripheral areas gain automatic compensation capability, accurate measurement of central and peripheral corneal thickness, is widely used in the preoperative examination and postoperative effect evaluation of refractive surgery.
Features
Large color liquid-crystal screen
Touch screen input, easy operation
Curve freezing: Manual/Auto mode, controlled by pedal
Built-in speed thermal printer
Technical Specifications
PARAMETER
SPECIFICATION
A scan probe
10MHz import small size probe, built-in luminotron
Measuring range
15mm-40mm
Measurement precision
±0. 05mm; with macula lutea trace func
Measurement
Anterior chamber depth, lens thickness, vitreous body length, total length and average
Method of measurement
immersion and contact
Eye mode
Phakic/ Aphakic/Dense/ various IOL
IOL formula
SRK-II,SRK-T,BINKHORST- Ⅱ,HOLLADAY,HOFFER-Q, HAIGIS Enter the name & ID; easy to check archive
Storage
10 cases, 5 readings each case
Output
A scan waveform and IOL calculation sheet
P scan probe
20MHZ, angle of 45 degrees makes easier operation
Resolution
5um
Measuring range
150um~1500um
Display
SINGLE mode and MAP mode Can display ultrasound waveform when measuring Each group is the average of 20 measurements Switch between IOP measured value and actual value Can input name, ID and operator’s name
