- Performance Characteristics
- Using the world’s top high-end flat panel detector, high resolution,
small distortion, uniform brightness.
- Use exposure mode, only when needed to activate the X source. During the rotation of the 18s, the rays last only 4-8s. The effect of reducing the check dose, reached the international advanced level.
- 3000A proprietary three-dimensional reconstruction algorithm, the original two-dimensional sequence projection into a three-dimensional volume image, you can at any angle, any location to provide high-definition tomography.
- through the three-dimensional volume image extraction of oral panorama, can provide high-definition panoramic images.
5, the image can be used to generate reports, print or save as a report file.
6, can provide standing, sitting and wheelchair and other kinds of film.
|III. Standard Configuration|
|1、Main Frame||1 set|
|2、High Frequency High Voltage X-ray Generator||1 set|
|3、19 inch color ordinary LCD monitor||1 set|
|4、12cmX15cm flat panel detector||1 set|
|5、Digital Acquisition Processing Workstation||1 set|
|6、Electrically adjustable collimator||1 set|
|7、Graphical LCD touch screen||1 unit|
|8、Wall-mounted control box||1 unit|
|9、Electrical control cabinet||1 unit|
|10、Printer (optional)||1 set|
- Technical Specifications
|Technical indicators||Anode voltage: 60-92 kV|
|anode current: 1-15 mA.|
|Maximum output power: 1.38kw|
|parameter adjustment range: 60 ~ 92KV 1 ~ 15mA|
|Information display: KV, MA, lifting position information, human characteristics, laser indication and positioning|
|X-ray tube||X-ray Tube Model: D-054SB (Toshiba)|
|Heat capacity: 35kJ (50kHU)|
|photography mode: cone beam CT|
|Image system Thales flat panel detector 650HD-E||image receiving size: 12cmX15cm flat panel detector|
|pixel size: 150|
|A / D conversion depth: 14bit|
|Acquisition mode: pulse mode|
|Detector Type: CMOS|
|Pixel matrix: 960 * 786|
|Limit resolution up to: two-dimensional ≥ 3.1 lp / mm|
|Structural Performance||Column lift stroke: 1000mm|
|Lifting noise: <70dB (with buzzer sound)|
|Collision protection: Yes|
|Dimensions: 788mm (width) X 1090mm (length) X 2200mm (height)|
|Power requirements: 220V / 50HZ / 2kVA|
|Space requirements: the required area of 5 square meters, unilateral 2 meters|
|The camera room should have a protective thickness of 2 mm lead|
|Electrical control device size: width 340mm, depth 550mm, height 650mm|
