Coagulation Analyzer AM-AR-5002

Features

  1. Advanced scattered light principle and percentage analysis ensure accurate results.
  2. Low reagent consumption less than 20uL, open reagent.
  3. Special testing cup location system, adding sample bracket
  4. Optional PT Derived method for testing fibrinogen, decease the dosage of reagent
  5. Advanced optical light matching system ensure precision result.
  6. 240* 128 large LCD display.
  7. Memory for 10.000 testing result
  8. Internal thermal-sensitive printer
  9. Electronically-linked pipette optional.
  10. Perform all routine tests such as PT. APTT. TT Fibrinogen and clotting factors
  11. RS232 interface, PC connecting for management software



Compare



Technical Specifications

PARAMETER SPECIFICATION
Testing channels 2 channel;2 different parameters analysis in the same time.
Sample pre-warming  position 16 positions
Reagent pre-warming  position 3 positions
Software timer 2
Test wavelength 470nm
Sample consume 20uL-40ul
Reagent consume 20uL-40uL
Temp control precision 37±0.3°C
Repeatability Cv < 2%
Coincidence indicator ≤3%
Memory 10000 test result
Notation of Result S, %, PTR, INR, g/L
Operation language English
Power supply 220VAC±15% 50-60Hz
Temperature 15°C-30°C wet≤90%
Packing size/G.W 370mm(L)×370mm(W)×120mm(H),8Kg

Usual Test List

Prothrombin  PT

Activated Partical Thromboplastintime  APTT

Thrombin Time  TT

Fibrinogen      FIB

RT, VT,VIII, IX,XI, XII,II, V, VII, X, PS, PC, Xa,etc
